CHROME STEEL BALL

Dezhou Sailing Import and Export Co., Ltd.

Chrome steel is known as GCr15 in China. It is manily used to make various bearing rings and rolling elements, such as: making steel for internal combustion engines, electric locomotives, automobiles, tractors, machine tools, rolling mills, drilling machines, mining machinery, general machinery, and high-speed rotating high-load mechanical transmission bearings balls, Rollers and Ferrules.

In addition to making balls, bearing rings, etc., it is sometimes used to make tools, such as dies and measuring tools.

AISI52100 Chrome Steel Ball
Material	AISI52100/SUJ2/GCr15/DIN 1.3505 Chrome Steel
Size	0.8mm to 150mm
Grade	G10-G1000
Hardness	60-66HRC
Features	(1) Comprehensive performance is good (2) High hardness and uniform (3) Wear resistance and contact Fatigue Strength are high (4) Thermal processing performance is good
Application	Chrome Bearing ball mainly used to manufacture steel balls, rollers and bushings on drive shafts such as internal combustion engines, electric locomotives, machine tools, tractors, Rolling equipment, dilling rigs, railway vehicles and mining machinery.

CHEMICAL COMPOSTIONS %
C	Si	Mn	P	S	Cr
0.90	0.15	0.25	0.025	0.025	1.30
1.10	0.35	0.45	max	max	1.60

Througgh Hardness Index:

Up to 12.70mm	HRC 62/66
From 12.70mm to 50.80mm	HRC 60/66
From 50.80mm to 70mm	HRC 59/65
From 70mm to 150mm	HRC 57/63

Mechanical Properties:

Critical Tensile Strength	228kgf/mm²
Compression Strength	207kgf/mm²
Modulus or Elasticity	20.748kgf/mm²
Specific Weight	7.830kgf/mm²
